Micro-Louvre panel G2
The Micro-louvre G2 is an updated luminaire for those situations where a more discrete ceiling presence is desired. By providing a specific lens and reflector/louvre cell for each LED package, the light distribution is tightly controlled while maintaining good levels of
efficiency. It retains a shallow profile in the ceiling, and there are options for surface-mounting and plaster recess (with optional frames) in both 600x600 and 300x1200 sizes. The G2 has an enhanced modularity with easily replaceable led array modules.
APPLICATIONS
Office
Commercial
Retail
SPECIFICATIONS
Power Factor:
>0.90
Electrical Input:
220 - 240 V / 50 - 60 Hz
FEATURES
Warranty:
5 years
Construction:
Moulded Plastic (PVC)
Standard Mounting:
Recessed
Standard Mounting:
Suspended
Life Prediction (hrs):
L80 > 102,000 hrs
Ingress Protection:
IP20
| PRODUCT CODE | DIMENSION (mm) | POWER | Luminous Flux | Optic/Beam | Colour Temperature | Colour Rending Index |
|---|---|---|---|---|---|---|
| EMP6X6W4KW9040-G2 | 595 x 595 x 31 mm | 18W - 36W | up to 1970 - 3660 lm | 80 degrees | 4000K | CRI90 |
| EMP3x12W4KW9040-G2 | 295 x 1195 x 25 mm | 18w - 36W | up to 2010 - 3715 lm | 80 degrees | 4000K | CRI90 |
