Deep Downlight G3
Ecopoint’s Deep Downlight achieves a low glare rating of UGR
<19, by virtue of a deep-set reflector design. This allows the fitting to be used with confidence in office environments and areas where workstations can be affected by the glare from adjoining luminaires. A Citizen COB light engine and good heatsink design combine to produce excellent lumen maintenance values. The G3 upgrade includes a wattage selectable driver as standard and better colour rendering.
APPLICATIONS
Office
Commercial
Retail
Residential
FEATURES
Warranty:
5 years
Construction:
Aluminium (cast)
Metal Finish:
Painted
Standard Mounting:
Recessed
Life Prediction (hrs):
L80@99,000 hrs
Ingress Protection:
IP20
| PRODUCT CODE | DIMENSION (mm) | POWER | Luminous Flux | Optic/Beam | Colour Temperature | Colour Rending Index |
|---|---|---|---|---|---|---|
| EDDR110W13W9040G3 | Ø 110 x 100 mm | 6 - 13W | up to 760 lm | Beam angle 45° | 4000K | ≥ 90 |
| EDDR190W18W9040G3-SD | Ø 190 x 127 mm | 13 - 25W | up to 1,600 lm | Beam angle 36° | 4000K | ≥ 90 |
| EDDR230W25W9040G3-SD | Ø 230 x 140 mm | 13 - 25W | up to 2,150 lm | Beam angle 45° | 4000K | ≥ 90 |
| EDDR230W35W9040G3 | Ø 230 x 140 mm | 35W | 2,900 lm | Beam angle 45° | 4000K | ≥ 90 |
| Deep Downlight G3 | Ø 110 x 100 mm | 6 - 13W | up to 760 lm | 45 deg | 4000K | ≥ 90 |
