Surface-Mount Ceiling Light

Ecopoint's surface-mount and suspended LED luminaires are ideal solutions in retail, supermarkets, offices and commercial buildings.
Surface-Mount Ceiling Light

Surface-Mount Ceiling Light

Ecopoint's surface mounted ceiling light is constructed from quality materials and uses an array of efficient SMD LEDs, a fire-rated diffuser and a robust steel mount. The luminaire is IP54 waterproof rated, making it ideal for locations where there are damp conditions. Installation is quick and easy as no cutout is required. Available in a variety of sizes and wattages, including a 12W emergency version.

APPLICATIONS

Office, Commercial, Retail

SPECIFICATIONS

Power Factor:
>0.9
Electrical Input:
200-240V AC / 50-60 Hz

FEATURES

Warranty:
3 years
Construction:
Moulded plastic (ABS), Polycarbonate (PC)
Standard Mounting:
Surface-mounted
Life Prediction (hrs):
L70 > 61,000 hrs (B50)
Ingress Protection:
IP54
Impact Protection:
IK08
PRODUCT CODE DIMENSION (mm) POWER Luminous Flux Optic/Beam Colour Temperature Colour Rending Index
ECL2504K12W 250 (dia) x 48 mm 12 W 1,090 lm 120 deg 4000K >80
ECL2504K12WE 250 (dia) x 48 mm 12 W 1,090 lm 120 deg 4000K >80
ECL3004K25W 300 (dia) x 40 mm 25 W 2,180 lm 120 deg 4000K >80
ECL3004K25WE 300 (dia) x 40 mm 25 W 2,180 lm 120 deg 4000K >80
